330ml-1L Water filling line

Customized solutions | Capacity 30,000 bottles/hour | 1L Water Filling Line

Our fully automatic water filling line is designed for 330ml to 1L bottles,

It ensures hygienic, contamination-free bottling for mineral water, purified water, and flavored beverages, which is of great significance for the quality of the final products.

The one-button start of the online cleaning function, along with the built-in spray ball and acid and alkali liquid circulation pipeline, significantly improves the cleanliness of the equipment.

Key Features Include

1、High-speed filling:

The production capacity can reach 2,000 to 30,000 bottles per hour (depending on the model), and the advanced PLC system accurately controls the flow to minimize downtime and ensure stable operation.

2、Fully automated process:

Made of food-grade stainless steel, it not only ensures product safety, but also improves the durability of the equipment.

3、Multi-station synchronization:

The equipment adopts an efficient rotary structure design, which supports 8~60 filling heads working at the same time, further improving the overall production efficiency.

4、CIP cleaning system:

The rotary design supports multiple filling heads working at the same time, greatly improving production efficiency.

Core Advantages

Production Rrocess

Detailed Parameters

Model	CGF8-8-4	CGF14-12-5	CGF18-18-6	CGF24-24-8	CGF32-32-10	CGF40-40-12
Capacity(500ML)	2000-3000BPH	3000-4000BPH	6000-8000BPH	10000-12000BPH	13000-15000BPH	16000-18000BPH
Floor area	300㎡	400㎡	600㎡	1000㎡	2000㎡	2500㎡
Total power	100KVA	100KVA	200KVA	300KVA	450KVA	500KVA
Opertor workers	8	8	6	6	6	6

Application Scenario

Customer Cases

Our 500ml–1L water bottling lines have been successfully installed and operated in Mexico, the Philippines, Canada, India, Saudi Arabia, and Germany, meeting diverse regional standards and production needs. Each project was customized based on local bottle shapes, plant layouts, and capacity requirements.
