Description
DCGF24-24-8 8000PH PET Bottle Carbonated Juice Filling Machine
Product Description
Automatic PET Bottle Carbonated Juice Filling Machine
1. Model DCGF24-24-8
2. Capacity: 8000BPH (500ml)
3. Applicable: plastic bottle 300ml-1000ml
4. Machine electric brand: Siemens, Mitsubishi, Schneider
5. Machine power: 5.5kw
7. Machine weight: 2800kg
7. Machine includes functions: filling, sealing.
8. Application: beverage,, juice.
| Technical parameter : carbonated beverage production line | ||||||
| Model | DCGF14-12-5 | DCGF16-16-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 | DCGF40-40-12 |
| Capacity(for 500ml) | 2000-3000 | 3000-4000 | 4000-5000 | 8000-9000 | 11000-12000 | 13000-15000 |
| Suitable bottle shapes | circular or square | |||||
| Bottle diameter(mm) | Dia50-Dia115mm | |||||
| Bottle height (mm) | 160-320mm | |||||
| Compressor air | 0.3-0.7Mpa | |||||
| Washing meidium | Aseptic water | |||||
| Rinsing pressure | >0.06Mpa <0.2Mpa | |||||
| Application | carbonated beverage production line | |||||
| Total power (KW) | 4.4kw | 4.8kw | 5.2kw | 6.2kw | 7.5kw | 8.2kw |
| Overall dimensions | 2.5*1.9m | 2.7*1.9m | 2.8*2.15m | 3.1*2.5m | 3.8*2.8m | 4.5*3.3m |
| Height | 2.3m | 2.5m | 2.5m | 2.5m | 2.5m | 2.6m |
| Weight(kg) | 3000kg | 4000kg | 4500kg | 6000kg | 8500kg | 10000kg |
Automatic PET Bottle Filling Machine -Mineral Water Filling Line with Advanced Bottle Washing System
Primary Use: The machine is designed to fill carbonated beverages, including carbonated juices.
Integrated Functions: It combines three key functions—bottle rinsing, filling, and capping—into one unified system.
Fully Automatic Process: The machine automates the entire operation, ensuring smooth, efficient, and precise filling.
Suitable Bottles: The machine works with bottles made of polyester and plastic, providing flexibility for various packaging needs.
Mineral Water Filling Line with Precision Filling and Cleaning Features
High Precision Flowmeter: Each filling valve pipeline features a high-precision flowmeter, ensuring accurate filling.
Capacity Parameter Package: The electrical control system includes a parameter package for each filling capacity, enabling precise adjustments for different production needs.
Accurate Filling: The filling volume for each valve can be set via the touch screen, with filling accuracy reaching up to 2‰. The filling valve does not contact the bottle neck, ensuring a clean process without secondary contamination.
Controlled Filling Process: The filling valve operates with a cylinder controlled by a solenoid valve, offering rapid filling initially, followed by a slower filling phase once the preset amount is reached.
Automatic Bottling Filling Machine - Mineral Water Filling Line with Precision Capping System
High Precision Capping: The capping machine, integrated into the 3-in-1 unit, offers the highest precision, significantly impacting product defect rates.
Reliability in Operation: The reliability of the capping machine plays a crucial role in ensuring consistent and smooth equipment operation, directly affecting product quality.
Advanced Technology: The machine incorporates cutting-edge Italian AROL capping technology, providing superior performance and reliability.
Collaborative Design: The design process involved collaboration with experts of Mechanical Engineering, focusing on electrical, mechanical, and automation technology to optimize the system.
Why Choose Us
Direct Manufacturer: With over 10 years of experience in developing and manufacturing beverage and liquid food filling machines. Our plant spans 4000m², and we have independent property rights.
Professional Export Team: We offer stable product quality, fast delivery, and clear communication, ensuring smooth international transactions.
Custom Manufacturing: Our skilled technical team can design machines in various sizes and configurations to meet your unique specifications.
Strict Quality Control: We never ship equipment without customer approval. Every machine undergoes 24-hour testing before shipping, and we ensure quality is controlled at every production stage.
12-Month Warranty: All our equipment comes with a 12-month warranty, and we provide lifetime technical support for all products.
Fast Spare Parts Availability: We supply spare parts quickly and at cost price, minimizing downtime and ensuring operational continuity.
