Description
DGF12-1 2500BPH 2-in-1 Filling Capping Juice Can Filling Machine
| GF 12-1 Two-in-One Filling and Capping Juice Can Filling Machine | ||
| 1 | Project | Technical parameters |
| 2 | Number of workstations | Filling 12, capping 1 |
| 3 | Maximum production capacity | 1500-2500 cans/hour |
| 4 | Gas source pressure | 0.4Mpa |
| 5 | Gas consumption | 0.02M3/min |
| 6 | Filling temperature | 10-85℃ |
| 7 | Empty can specifications | Diameter, ф53～66mm |
| 8 | Empty can height | 70～175mm |
| 9 | Filling accuracy | ±5mm (liquid level positioning) |
| 10 | Filling method | Normal pressure filling |
| 11 | Main motor power | 0.75KW |
| 12 | Rated voltage | 380V |
| 13 | Dimensions | 2100*1300*2000mm |
| 14 | Equipment weight | 1600kg |
Filling System
Filling valve uses a high-precision mechanical design for fast filling and accurate liquid levels.
Filling cylinder, made of 304L material with an annular seal, enables isobaric filling.
The filling valve flow rate exceeds 125 ml/s.
The main drive combines a toothed belt and open gearbox for high efficiency and low noise.
Variable frequency stepless speed control and PLC industrial computer regulate the whole machine; a coupling connects the filler and seamer to ensure synchronization.
Capping System
The machine fills only when cans are present, preventing waste.
The can sealing system adopts advanced Swiss (Rerrum) technology.
Sealing roller is made of high-hardness alloy steel (HRC > 62) and precisely ground with optical curve processing for superior sealing quality. The bottle guide adjusts to different bottle types.
Control system ensures lids lower only when cans are present, maintaining smooth operation.
Why Choose Us
Direct Manufacturer: With over 10 years of experience in developing and manufacturing beverage and liquid food filling machines. Our plant spans 4000m², and we have independent property rights.
Professional Export Team: We offer stable product quality, fast delivery, and clear communication, ensuring smooth international transactions.
Custom Manufacturing: Our skilled technical team can design machines in various sizes and configurations to meet your unique specifications.
Strict Quality Control: We never ship equipment without customer approval. Every machine undergoes 24-hour testing before shipping, and we ensure quality is controlled at every production stage.
12-Month Warranty: All our equipment comes with a 12-month warranty, and we provide lifetime technical support for all products.
Fast Spare Parts Availability: We supply spare parts quickly and at cost price, minimizing downtime and ensuring operational continuity.
